How to ? Save measurements
Save measurements
Use this procedure to save measurements to a spreadsheet or text format:
1. Measurements that you want to save must be selected.
2. From the File menu select Save or Save As. Under Save What, click Measurement.
3. Click the Options button to open the Measurement Save Options dialog box.
4. Select the Measurement Format from the drop-down list.
5. Click OK to save the measurement options, or click Cancel to close the dialog box without saving
the changes.
6. To save the measurements to a file, select the location to sa
ve from the Save in drop-down list. The
default location is
C:\Users\[Username]\Tektron ix\TekScope\data.
7. Use the default name for your file, type a unique name into the Name text box, or select an existing
name from the Name list (data in the existing file will be overwritten). You can also select the
Auto-increment file name check box to save a series of files without typing in a n ew name each time.
8. Select the file type from the Save as type drop-down list; this is the same as the Measurement format
that you selected in the Options dialog box.
Use .cvs for spreads heets.
Use .txt for text.
NOTE. Changing the file type here will also change the selected format in the Option dialog.
9. Click Save.
Using math waveforms
Use the same techniques to work with math waveforms that you use with channel waveforms. This
procedure demonstrates some common operations that you can perform on math waveforms:
NOTE. Math calculations are not available on digital channels.
NOTE. Each math waveform you create derives its horizontal scale and position from the sources you
include in its math expression. You can adjust these controls for the source waveforms, and your
adjustments are reflected in the math waveform.
You can also magnify math waveforms using MultiZoom, and use the mouse for positioning.
606 DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series
