Vertical Setups Probe Setup Control Window: Probe Tip Selection
Probe Setup Control Window: Probe Tip Selection
From the Vertical menu, select Probe Cal, and then click the Probe Tip Select button.
NOTE. Some probes have more than one type of probe tip available. The type of probe tips in the selection
window chang
e according to the probe connected to the instrument. Refer to the probe instructions
manual for more information on the tips available for your probe.
To use
1. Select the type o f probe tip to match the one you are using.
2. Click OK.
Here is an
example of Probe Tip for Tektronix P73XX probe.
504 DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series
