Piston(Traction)PumpInstallation(Figure87)(continued)
8.Removeplugsandcapsfromdisconnectedhydraulichosesandttingsof
thepumpassembly.Installhydrauliclinestocorrectlocationongearand
pistonpumps(seeInstallingtheHydraulicFittings(SAEStraightThread
O-RingFittings)(page5–9)andInstallingHydraulicHosesandTubes
(O-RingFaceSeal)(page5–7)).Tightensuctionhoseclampfrom3to5
N·m(30to45in−lb).
9.Usinglabelsplacedduringpumpremoval,connectwireharnessconnectors
tothetwo(2)solenoidcoilsonleftsideofpistonpump(Figure88).
10.Lowermachinetoground.
IMPORTANT
RefertoTractionCircuitComponentFailure(page5–5)for
informationregardingtheimportanceofremovingcontamination
fromthetractioncircuit.
11.Installnewhydrauliclterandllhydraulicreservoirwithcorrectoil.
12.Primehydraulicpumps(seePrimingHydraulicPumps(page5–76)).
13.Properlyllhydraulicsystem(seeChargeHydraulicSystem(page5–79)).
14.Stopengineandcheckforhydraulicoilleaks.Checkhydraulicreservoiroil
levelandadjustifnecessary.
15.Installsideshroudsifpreviouslyremovedandclosehood(seeHoodand
LowerShrouds(page7–47)).
Groundsmaster
®
5900&5910
Page5–97
HydraulicSystem:ServiceandRepairs
16227SLRevB
