Toro Groundsmaster 5910 Series User Manual

OperatorInformationScreen
1
2
3
4
5
76
8
8
g288304
Figure140
1.Button15.Button5
2.Button2
6.Leftgaugescreen(coolanttempshown)
3.Button3
7.Rightgaugescreen(hydraulicoiltemp
shown)
4.Button48.Fanspeedindicator
TheInfoCenterreplacestraditionalgaugesbydisplayingengineandmachine
status.TheoperatorinformationscreenisthedefaultInfoCenterscreenandis
displayedwhenthekeyswitchisineithertheRUNorSTARTposition.See
themachineOperator’sManualforadditionaloperatorinformationscreen
information.
Theupperleftportionofthescreenisusedtodisplayanyofthree(3)different
gauges:
•Enginecoolanttemperatureandradiatorcoolingfanspeed/direction
•EngineRPM
•Electricalsystemsvoltage
Theupperrightportionofthescreenisusedtodisplayanyoftwo(2)different
gauges:
•Hydraulicoiltemperatureandhydraulicoilcoolerfanspeed/direction
•Fuellevel
Toselectthedesiredgauge,exposetheInfoCenternavigationpanebypressing
anybutton1,2,3or4onthedisplay(Figure140).Fromthenavigationpane,
pressingbuttons1or2onthedisplayscrollsthroughthevariousgaugeoptions.
Note:Thenavigationpanewillautomaticallycloseafterashorttimeoritcanbe
closedmanuallybypressingbutton5undertheopendooricon.
Thelowerportionofthescreenisusedtodisplaythefollowingconditions(see
machineOperator’sManual):
•Machinehours
•EngineRPM
•Tractionspeedrange
•DieselParticulateFilter(DPF)regenerationstatus
•Glowplugs(energized)
Groundsmaster
®
5900&5910
Page6–11
ElectricalSystem:InfoCenterDisplay
16227SLRevB
