OperatorInformationScreen(continued)

•PTO(engaged)

•Parkingbrake(engaged)

•Enginecoolingfan(inreverse)

•Cruisecontrol(engaged)

g288305

Figure141

1.Button14.Button4

2.Button25.Button5

3.Button36.Displaycontrols

InfoCenterdisplaycontrolscanbeaccessedbypressingbutton5onthedisplay

(Figure141).Whenthedisplaycontrolsappear,usebuttons1or2toadjust

thedisplayscreenbrightness,andbuttons3or4toadjustthedisplayscreen

contrast.

Returntothepreviousscreenbypressingbutton5.

ElectricalSystem:InfoCenterDisplay

Page6–12
