Toro Groundsmaster 5910 Series User Manual

Adjustment(continued)
1
2
3
4
Switch to Sensing Plate Clearance
2.4 to 3.9mm (0.095 to 0.155 in)
g288432
Figure189
1.Wingdeckliftarm3.Switchbracket
2.Positionswitch
4.Sensingplate
5.Formachineserialnumbersbelow316000200adjustthewingdeckswitches
asfollows(Figure189):
A.Raisethewingdecktoa12degreeangleandsafelysupportthedeckto
preventitfromloweringduringtheadjustmentprocedure.
B.Loosenthelocknutsecuringtheswitchtotheswitchbracketandset
thepositionswitchsothecorrectclearanceexistsbetweenthetarget
eyeandthesensingplate.
C.Setthepositionswitchsothesensingeyeoftheswitchisattheupper
edgeofthesensingplate.Loosenthesensingplatemountingfasteners
toadjusttheplateasneeded.
6.3 mm
(0.25 in)
1
2
3
2.4 to 3.9 mm (0.095 to 0.155 in)
Switch to Sensing Plate Clearance
g288433
Figure190
1.Wingdeckliftarm3.Sensingplate
2.Positionswitch
ElectricalSystem:Adjustments
Page6–48
Groundsmaster
®
5900&5910
16227SLRevB
