Figure241
1.YanmarECU3.Glowplugrelay
2.Startrelay
ThefollowingrelaysarelocatedontheleftsideoftheengineneartheYanmar
ECU(Figure241):
•Thestartrelaysuppliespowertotheenginestarter.Theglowplugrelayis
energizedbytheYanmarECU.
•Theglowplugrelaysuppliespowertotheengineglowplugs.Theglowplug
relayisenergizedbytheYanmarECU.
1
2
g288553
Figure242
1.Cabheadliner(roofremoved)
2.Airconditionerrelay
TheairconditionerrelayusedontheGroundsmaster5910suppliespowertothe
airconditioningsystemevaporatorfansandthecompressorclutch.Thisrelayis
energizedwhenthekeyswitchisintheSTARTorRUNposition(cabcontactor
closed),thefanspeedswitchissettolow,mediumorhighspeedandtheair
conditioningswitchissettoON.Theairconditionerrelayislocatedinthecab
headlinernearthefuseblock(Figure242).T oaccesstherelay,removeroof
panelfromtopofcab(seeRoofAssembly(page9–9)).
Testing
1.MakesurekeyswitchisOFF .Removekeyfromkeyswitch.
2.Turnbattery−disconnectswitchtotheOFFposition.
3.Verifythelocationoftherelaybeingtested(above)andaccesstherelay.
ElectricalSystem:ComponentTesting
Page6–100
