Removal(Figure348)(continued)
4.ReadtheGeneralPrecautionsforRemovingandInstallingAirConditioning
SystemComponents(page9–4).
CAUTION
Theairconditioningsystemisunderhighpressure.Donotloosen
anysystemttingorcomponentuntilafterthesystemhasbeen
completelydischargedbyacertiedA/Cservicetechnician.
5.HaverefrigerantevacuatedfromairconditioningsystembyacertiedA/C
servicetechnician.
6.Labelanddisconnecthosesfromcondensercore.Immediatelycaphoses
andttingstopreventmoistureandcontaminantsfromenteringthesystem.
7.Removefour(4)angenutsthatsecureA/Ccondenserassemblytocab
frame.
8.Carefullyraisecondenserassemblyfromheadlinerandremovefrom
machine.
g299874
Figure349
1.Condensercore7.Leftsidewall
2.Lowerleg(2)8.Stripseal(2)
3.Hexnut(6)9.Edgeseal(2)
4.Frontwall
10.Screw(12)
5.Backwall
11.Clip(16)
6.Rightsidewall
9.Inspectseals(items7and8inFigure348)ontopofcabframeforwear
ordamageandreplaceifneeded.
10.Ifnecessary,disassemblecondenserassemblyusingFigure349asaguide.
Inspectsealsontopofcondenserassemblywalls(items8and9inFigure
349)forwearordamageandreplaceifneeded.
Groundsmaster
®
5900&5910
Page9–17
OperatorCab:ServiceandRepairs
16227SLRevB
