Page II-35
180 DSP Operation Manual
Signal Level Meter
The Measure screen will be displayed as
shown in the image to the right. This screen
allows you to modify the measurement
settings of the 180 DSP.
From within the Measure screen, use the
left/right arrow buttons on the keypad to
navigate through the list of setup items.
Measurement Settings
Select the Measure button as shown
in the image to the right to adjust the
measurement settings for the 180 DSP.
These parameters can be set directly from your instrument
or using the ViewPoint WFM Module. For instructions
regarding setup using ViewPoint, please refer to the ViewPoint
Operation Manual.
