Page IV-158
180 DSP Operation Manual
Signal Level Meter
Function Menu Options
Additional functions can be accessed from
within the QAM EVS screen by pressing the
Function button. The Function menu will
be displayed as shown in the image to the
right and includes the following functions
specically for the QAM EVS screen.
Hide Marker Bar
Select the Hide Marker Bar button from
the Function menu to hide the marker bar
at the bottom of the screen and expand
the measurement viewing area.
When the marker bar is hidden, select
the Show Marker Bar button from the
Function menu to show the marker bar.
