www.trilithic.com
Page IV-156
180 DSP Operation Manual
Signal Level Meter
Minimum
Select the Minimum button from the
Detector pop-up menu to display the
minimum level of the QAM EVS as a blue
trace that appears on the screen over the
green live trace.
Normal
Select the Normal button from the
Detector pop-up menu to display the
normal live level of the QAM EVS as a
green trace.
