Trilithic 180 DSP User Manual

www.trilithic.com
Page I-45
180 DSP Operation Manual
Signal Level Meter
Accessing the 180 DSP Remotely
The 180 DSP enables you to remotely
access the device using any active network
connection.
After making a successful connection to a
network, use the Network Manager window
to determine the IP address of the 180 DSP
as shown in the image to the right.
Once you have the IP address of the 180
DSP, enter this value into the address bar of
a web browser.
The web browser will display a list of links to specic functions as shown
in the image to the right. From this list, select the function that you would
like to perform as follows:
• Remote Control – This is used to display a web page with a
control layout similar to the 180 DSP. From this page you can
control almost any function of the 180 DSP.
• Log File – This is used to display a web page that includes all of the information
currently stored in the log le of the 180 DSP.
• System Stats – This is used to display a web page that includes graphs related to
system processor and memory usage statistics over time.
• Screen Shot – This is used to display a web page that includes a screen shot of the
current 180 DSP display screen.
• Files – This is used to display a web page that includes all of the les stored on the
internal memory of the 180 DSP.
Remote Access
Chapter 5
