Trilithic 180 DSP User Manual

www.trilithic.com
Page VI-9
180 DSP Operation Manual
Signal Level Meter
Available Interface Types
Tx Test Port
(1.2 GHz RF board
only)
75 Ohm Replaceable F-Type Connector
Source Generator Output Transmission Only
Tx/Rx Test Port
75 Ohm Replaceable F-Type Connector
Upstream & Downstream RF Measurements
Ethernet RJ45 Ethernet Port (10/100 Mbps)
USB USB 2.0 Type-A Standard Port
Bluetooth
(Optional)
Class II Mini Bluetooth USB Adapter (v2.1) with a 10 meter range for
speeds up to 3 Mbps
Operating Time 4 to 5 hours, dependent on use
Charge Time 4 hours
Battery One 2600 mAh @ 7.4V Li-Ion internal battery, factory replaceable
Power Adapter
Input: 100 to 240 VAC ~ 47 to 63 Hz, 1.1A Max
Output: 15 VDC, 3.3A
Battery & Power Specications
Storage &
Operating
Temperature
-18˚ to +50˚ C (0˚ to 122˚ F)
Environmental Specications
