www.trilithic.com
Page IV-123
180 DSP Operation Manual
Signal Level Meter
When nished entering the test point
loss information, press the Back
button to return to the Full Spectrum
screen.
The total test point compensation
value will be displayed, as shown in
the image to the right.
Load Preset
Select the Load button to load the
test point values preset.
If you have multiple presets, the
Test Point Presets window will be
displayed. Choose the preset you
would like to load.
