Trilithic 180 DSP User Manual

www.trilithic.com
Page I-40
180 DSP Operation Manual
Signal Level Meter
Bluetooth Connection (OPTIONAL)
Perform the following steps to connect to an iPad using the optional Bluetooth connection:
1. Make sure the iPad is turned on
and the Bluetooth is enabled.
2. Insert the USB Bluetooth adapter
into the USB port of the 180 DSP.
3. Select the Bluetooth connection
button from the Network Manager
window as shown in the image to
the right.
4. If the Prompt User option is set
to Yes from within the Bluetooth
Settings option of the Setup
menu, the Bluetooth Settings
window will appear as shown in
the image to the right. Adjust the IP
and Subnet Addresses as needed
and then select the Login button.
5. The Bluetooth Settings window
will display the network connection
progress as shown in the image to
the right.
6. On the iPad, select the name of
the Trilithic Device from the list of
discoverable Bluetooth devices.
The name of the Trilithic Device will
be in the format of “tri-#####-#”.
If the Prompt User option is set to No from within the
Bluetooth Settings option of the Setup menu, the Bluetooth
Settings window will not appear. If so, proceed to Step 4.
