Trilithic 180 DSP User Manual

www.trilithic.com
Page I-35
180 DSP Operation Manual
Signal Level Meter
Screen Capture
This function is used to take a screen capture
of the currently displayed screen. To take a
screen capture, select the Screen Capture
function from the Function menu as shown
in the image to the right.
If you have an open job, you can also save
the screen capture to the job by selecting Yes
as shown in the image to the right.
If you don’t want to save the test to the open
job, select No and you will be prompted
to enter a le name using the Virtual
Keyboard. It will then be saved to the
internal memory of the 180 DSP.
To view the les saved to the internal memory of the 180 DSP,
see Section II: Setup, Chapter 4: File Management.
