November, 1998
8
Dismounting/Repair Brewing SystemService Manual FB50/55/5100/5500
● Dismount the brewer.
● Remove the brewer cylinder, the filter
plate support, and the scraper.
● Remove the four screws (1). (Fig. 1)
● Remove the product container
console (2). (Fig. 1)
● Remove the three screws (3). (Fig. 1)
● Remove the brewer housing (4).
(Fig. 1)
9.2.5Removing the Brewer Housing
Fig. 1
4
3
2
1
