Wittenborg FB 5100 - Dismounting the Mixer Motor

8
Dismounting the mixer motor
Procedure
Step Action
1.
Open the cabinet door, turn off machine (main switch), pull out the power
supply plug and close the water cock.
2.
Remove the ingredient canister.
3.
Remove the funnel extension, the mixing funnel and the whipper housing
(1).
4.
Remove the ingredient canister shelf (loosen 4 screws) (2).
5.
Remove the protective cover (3).
6.
Remove one of the dosing motors (4) to allow for space for dismounting
mixer motor.
7.
Remove whipper blade (6) and whipper blade gasket (5).
8.
Disconnect the electrical connection for the mixer motor in question.
9.
Remove the mixer motor (7) to the back.
3
2
4
7
5
1
6
