Wittenborg FB 5100 - Dismounting the Door Lock

8
Dismounting the door lock
Procedure Follow this procedure to dismount the door lock:
Step Action
1.
Open the cabinet door, turn off machine (main switch), unplug the
power supply plug and close the water cock.
2.
Dismount the trim bracket by loosening the screws (1) at the top, middle
and bottom.
3.
Dismount the locking latch (2).
4.
Dismount the lock (3).
3
1
2
