Wittenborg FB 5100 - Dismounting the Colour Panel

7
Dismounting the colour panel
Procedure Follow this procedure to dismount the colour panel:
Step Action Illustration
1.
Open the door, turn off the machine (main switch), unplug the power
supply plug and close the water cock.
2.
Dismount door cover (1).
3.
Loosen the thumbscrews
(2).
4.
Pull the colour panel (3)
forwards on the front side
of the door.
1
2
3
