Dismounting/Repair Brewing SystemService Manual FB50/55/5100/5500
Fig. 1
9.2.14Dismounting the Ejector Spring
● Remove the four screws (1) of the brewer
cylinder support (2). (Fig. 1)
● Press the spring (3) towards the back by
means of a screw driver, and remove it to
the side. (Fig. 1)
Mounting instruction:
The spring has to be placed between the
fastening domes and the spring guide (see
fig. 1).
1123
