Dismounting the water pipes
Procedure
Note If the connecting sockets are heavily calcified they must be replaced.
Wet the connecting sockets with drinking water before inserting the water
pipes. Make sure the water pipes are positioned correctly to prevent the de-
velopment of water pockets.
Step Action
1.
Open the cabinet door, turn off the machine (main switch), pull out the
power supply plug and close the water cock.
2.
Remove the ingredient canisters.
3.
Remove the funnel extensions and the mixing funnels (1).
4.
Remove filter bracket (2).
5.
Remove the ingredient canister shelf (loosen 4 screws) (3) (see
Dismounting mixer motor).
6.
Tilt ingredient canister unit forward.
7.
Remove the water pipes (4) by pulling them out of the connecting
socket from the back.
4
2
1
3
