Wittenborg FB 5100 - Replacing the Gaskets of the Brewer Cylinder

November, 1998
24
Dismounting/Repair Brewing SystemService Manual FB50/55/5100/5500
Fig. 1
12
Fig. 2
9.2.15Replacing the Gaskets of the Brewer Cylinder
Observe the safety instructions (see
section "Dismounting the Brewer
Unit").
● Remove the brewer cylinder.
● Remove the plunger from the brewer
cylinder.
● The valve with the gasket (1) is located in
the centre of the plunger. (Fig. 1)
Press the four supports of the valve
together, and pull the valve downwards.
(Fig. 2).
● Remove the outer gasket (2) by pulling the
sealing lip. (Fig. 1)
Note:
When replacing the gaskets, it is
absolutely necessary to replace
older versions of the plunger or
brewer cylinder by the up-to-date
versions.
● Replace the gaskets.
● The mounting is done in reverse order.
