Dismounting the power supply cable
Procedure
Note for reconnec-
tion
Make sure the connection is made correctly:
Step Action
1.
Loosen the tension relief screw at the power supply cable lead-through.
2.
Disconnect the cable connection at the terminal strip.
3.
Remove the power supply cable to the back.
Parts
1.
1L (blue)
2.
2L (brown)
3.
protective earth (yellow/green)
1
blue
2
3
brown
yellow/green
