7
Dismounting the cup platform
Procedure Follow this procedure to dismount the cup platform:
Step Action Illustration
1.
Open the cabinet door, turn off machine (main switch), unplug the
power supply plug and close the water cock.
2.
Remove the O-ring (1).
3.
Pull the arm for cup platform
down (2).
4.
Remove 2 screws (3).
5.
Remove the complete cup
platform.
3
1
2
