Wittenborg FB 5100 - Testing the Brewer Unit; Testing the Brewer Unit Next to the Dispenser

November, 1998
7
Dismounting/Repair Brewing SystemService Manual FB50/55/5100/5500
Testing the brewer unit next to the
dispenser
Connect the hose to the water
inlet elbow (1), and put the
elbow into a container, so that
the water does not run into
the dispenser. (Fig. 1)
● Plug the adapter cable harness (2)
(for service parts refer to the spare
parts list) between the 15-pole plug
of the brewer unit and the connection
socket of the brewer unit in the
dispenser. (Fig. 2)
● Actuate the safety switch.
There is an increased risk of
injuries. Keep parts of your
body and loose clothing away
from the brewer.
Fig. 2
2
9.2.4Testing the Brewer Unit
Fig. 1
1
