Wittenborg FB 5100 - Dismounting the Info Display

9
Dismounting the info display
Procedure Follow this procedure to dismount the info display:
Step Action
1.
Remove the button module.
2.
Disconnect the electrical connections to the info display.
3.
Remove 4 screws (1), then remove the LCD module with the info
display.
4.
Remove 4 screws (2) in the LCD module frame (3), then remove the
info display (4).
2
1
4
3
