November, 1998
29
Dismounting/Repair Brewing SystemService Manual FB50/55/5100/5500
General note:
When replacing the dosing motor, the side parts have to be cleaned. Silicone remnants
have to be removed by means of alcohol.
Up-to-date parts can be recognized by the below stated
remarks, all other versions have to be replaced by the following
parts:
with ball bearing
grey parts with microswitches (microswitches cannot be
dismounted because of a one-way snap function
for part-no. see spare parts list
for part-no. see spare parts list
Part:
Spindle
Premounted assemblies:
Base console
Inner tube and plunge
holder, plastic nut
Spindle with ball bearing, assy.
