6
Dismounting the dosing motor
Procedure
Step Action Illustration
1.
Open the cabinet door.
2.
Turn off machine (main switch), pull out the power supply plug.
3.
Remove the ingredient canisters.
4.
Take off the funnel extensions
and remove the mixing
funnels and the whipper
housing.
5.
Remove the ingredient
canister shelf by loosening
screws (1)
6.
Disconnect the electrical
connection.
7.
Remove the dosing motor by
loosening screws (2)
1
2
