Wittenborg FB 5100 - Page 183

11
These are the parts of the espresso brewer:
Maintenance
Requirements
The espresso brewer is easily maintained. Simply follow these principles
in order to avoid espresso brewer malfunctioning:
Parts
1.
Bracket, espresso brewer
2.
Switch
3.
Water outlet tube
4.
Spindle
5.
Gear wheel
6.
Securing pin
7.
Espresso brewer motor
8.
Coffee outlet tube
9.
Ground coffee inlet
10.
Scraper
11.
Waste guide outlet
12.
Holder for outlet
13.
Heat insulation cover
14.
O rings
15.
Filter
16.
Piston
17.
Ground coffee chute
Nature Parts Frequency
Service Consumable
Parts
O-rings of brewing
chamber
Replace after every
20,000 dispensings
Brewer motor Replace after every
60,000 dispensings
