Description The Selection Panel consists of:

• Pre-selection Buttons

• Selection Buttons

The Selection Panel is situated in the middle of the Selection Module.

Press the Pre-selection Button for strength

Press the Selection Button for coffee with whitener

Take away your cup of coffee dispensed.
