List of items FB
Note If installed with a payment system, the machine is installed with either the
coin mechanism (and other coin components) or the card reader.
Parts
1.
Colour panel
2.
Coin insert
3.
Coin return motor
4.
Card reader
5.
Cover, top with adhesive tape
6.
Outer housing for FB canister
7.
Cover
8.
Trim bracket
9.
Door lock
10.
Cup sensor
11.
Cover for inspection hole
12.
Protective cover, dispensing area
13.
Inner housing, dispensing area
14.
Pot platform
15.
Pot platform guide
16.
Door cover
17.
Cup platform
18.
Coin chute
19.
Cash box
20.
Door switch
21.
Coin mechanism
22.
Reinforcement panel, SPC print board
23.
SPC print board
24.
Display
25.
Selection panel, operating unit
