2660 Monitoring 2 [On] Operating range monitoring is carried
out according to the following
parameters.
O󰈠 Monitoring is disabled.
2663 Delay 2 1 to 999 s
[30 s]
If one of the above mentioned
conditions for an operating range
failure is ful󰈡lled for the delay time
con󰈡gured here, the appropriate
alarm will be issued.
2661 Alarm class 2 Class A/B/C/D/E/F/Control
[B]
Each limit may be assigned an
independent alarm class that speci󰈡es
what action should be taken when the
limit is surpassed.
Notes
For additional information refer to ╚═▷
“9.4.1 Alarm Classes”
2662 Self acknowledge 2 Yes The control unit automatically clears
the alarm if the fault condition is no
longer detected.
[No] The control unit does not
automatically reset the alarm when
the fault condition is no longer
detected.
The alarm must be acknowledged and
reset by manually pressing the
appropriate buttons or by activating
the LogicsManager output "External
acknowledgement" (via a discrete
input or via an interface).
2678 Monitoring lockable 2 Yes Monitoring for fault conditions is only
performed if "Lock Monitoring Status
24.40 is false".
[No] Monitoring for this fault condition is
continuously enabled regardless of
"Lock Monitoring Status 24.40".
4.3.6
CAN Interface
General notes
The CANopen interface is monitored. If the interface does not receive a Receive Process
Data Object (RPDO) before the delay expires, an alarm will be initiated.
If this protective function is triggered, the display indicates "CANopen interface 1" and
the logical command variable "08.18" will be enabled.
