Woodward LS-5 v2 Series User Manual

easYgen-3000
12
A12
LS-5x2
10
System A
System B
A05
DIs./Analog Inputs
GCB Control
Current (3Ph)
MPU/ECU
Voltage (3Ph)
Engine Start/Stop
Voltage (1Ph)
MCB Control
Current (3Ph)
Voltage (3Ph)
Voltage (3Ph)
Segment
No.
GGB Control
Current (1Ph)
LOAD
Segment
No.
CAN bus
11
Segment
No.
Fig. 158: One easYgen-3500XT with one LS-5x2 (example)
6.5.3
Multiple easYgen-3500XT (Mode GCB/L-GGBMCB) with LS-522 as
separate mains decoupling device
The easYgen-3500(XT) performs an island and mains parallel operation. The easYgen and
the LS-522 act simultaneously as protection devices for mains decoupling. The
easYgen-3500(XT) operates the GCB according to the application mode 'GCB/L-GGBMCB'.
The LS-522 contains the counter part of mains decoupling function in regards of FNN VDE-
AR-N 4105 needs. It operates the GGB and the MCB according to the application mode 'L-
GGBMCB'.
This mode is only supported by the easYgen-3500XT version 1.13 and higher.
291LS-5 v2 Series37650
6 Application
6.5 Setup VDE-AR-N 4105 Applications
Released
