Woodward LS-5 v2 Series User Manual

No. Name Function Note
• System A and B are already
connected and
• Angle is in range (parameter
8821, 8822) and
• Parameter "Connect synchr.
segments (8852) is "Yes"
and
• CBA is enabled and CBB is
closed
or
CBB is enabled and CBA is
closed and
•
System A is ok and
• System B is ok.
9.3.4.5 Group 05: Device Related Alarms
• Device related alarms
• Logic command variable 05.15
These device alarms may be used as command variable in a logical output to set
parameters for customized operations.
No. Name / Function Note
05.15 EEPROM failure TRUE = alarm latched (triggered)
FALSE = alarm acknowledged
9.3.4.6 Group 06: System B Related Alarms
• System B related alarms
•
Logic command variable 06.21
These system B alarms may be used as command variable in a logical output to set
parameters for customized operations.
No. Name / Function Note
06.21 SyB. phase rotation TRUE = alarm latched (triggered)
FALSE = alarm acknowledged
9.3.4.7 Group 07: System A Related Alarms
• System A related alarms
• Logic command variables 07.05-07.30
These system A alarms may be used as command variable in a logical output to set
parameters for customized operations.
413LS-5 v2 Series37650
9 Appendix
9.3 LogicsManager Reference
Released
