9.3.4.11 Group 11: Clock And Timer
•
Clock and timer
•
Logic command variables 11.01-11.07
Time functions may be used as command variable in a logical output.
No. Name / Function Note
11.01 Timer 1 (exceeded) Refer to parameters 1652, 1651 and 1650.
11.02 Timer 2 (exceeded) Refer to parameters 1657, 1656 and 1655.
11.03 Active weekday (equal to setting) Refer to parameters 1670, 1671, 1672, 1673,
1674, 1675 and 1676.
11.04 Active day (equal to setting) Refer to parameter 1663 .
11.05 Active hour (equal to setting) Refer to parameter 1662.
11.06 Active minute (equal to setting) Refer to parameter 1661.
11.07 Active second (equal to setting) Refer to parameter 1660.
9.3.4.12 Group 13: Discrete Outputs
• Discrete outputs
•
Logic command variables 13.01-13.06
The discrete outputs may be used as command variable in a logical output.
No. Name / Function Note
13.01 Discrete output DO1 [R01] TRUE = logical "1" (this condition indicates the
logical status of the internal relays)
FALSE = logical "0" (this condition indicates the
logical status of the internal relays)
13.02 Discrete output DO2 [R02]
13.03 Discrete output DO3 [R03]
13.04 Discrete output DO4 [R04]
13.05 Discrete output DO5 [R05]
13.06 Discrete output DO6 [R06]
9.3.4.13 Group 17: Alarm System 2
• Alarm system 2
• Logic command variables 17.01-17.14
These command variables may be used as command variable in a logical output.
No. Name / Function Note
17.01 Missing member 4105
17.02 Parameter alignment 4105
17.03 Measurement di󰈠erence 4105
17.08 Decoupling CBA<-> CBB
416 LS-5 v2 Series 37650
9 Appendix
9.3 LogicsManager Reference
