Mode Symbol Mode Symbol Function
This application mode provides the following functions:
• Handling of CBA (dead bus closure, synchronization, open)
initiated by the corresponding command variables or by
manual commands.
• Measuring and monitoring of system A values (voltage,
frequency, phase rotation, current).
•
Measuring of active and reactive power on system A.
• Measuring of phase angle system A to system B.
• Interacting as an independent synchronizer for a PLC by
communication interface (CANopen, Modbus RTU slave).
• Handling of CBB (dead bus closure, synchronization, open)
initiated by the corresponding command variables or by
manual commands.
• Measuring of system B values (voltage, frequency, phase
rotation, current).
•
Measuring of active and reactive power on system B.
• Mains decoupling function in the LS-5 con󰈡gurable, for LS-5
connected with system A at mains.
• Calculating of an active and reactive load.
6.1.2
LS-5x2 & easYgen-3400/3500 or easYgen-3400XT/3500XT:
Common Application Modes
For information on the easYgen genset control unit's application modes refer to the
easYgen manual.
6.1.2.1
LS-5x2 View
LS-512/LS-522 easYgen-3400/3500 or
easYgen-3400XT/
3500XT
Mode Symbol Mode Symbol Function
LS5
A02
GCB/LS5
A07
Open LS-5 system, in combination with easYgen-3400/3500 or
easYgen-3400XT/3500XT, individually con󰈡gurable. Multiple LS-5x1
and LS-5x2 are allowed. The breakers CBA and CBB are operated.
This application mode provides the following functions:
• Handling of CBA (dead bus closure, synchronization, open)
initiated by the corresponding command variables or by
manual commands.
•
Measuring and monitoring of system A values (voltage,
frequency, phase rotation, current).
• Measuring of system B values (voltage, frequency, phase
rotation, current).
•
Measuring of active and reactive power on system A.
• Measuring of phase angle system A to system B.
• Recognition of segments within the easYgen / LS-5 system.
•
Dead bus arbitration with other easYgen and LS-5.
257LS-5 v2 Series37650
6 Application
6.1 Application Modes Overview
