Once the conditions of the
LogicsManager have been ful󰈡lled the
alarms will be acknowledged.
The 󰈡rst high signal into the discrete
input acknowledges the command
variable 01.12 (horn).
The second high signal acknowledges
all inactive alarm messages.
Notes
For information on the LogicsManager
and its default settings see ╚═▷ “9.3.1
LogicsManager Overview”.
12959 Lock Monitoring 2 Determined by
LogicsManager
[(DI 01 & 1) & 1]
As long as the conditions of the
LogicsManager have been ful󰈡lled, all
monitoring functions which are
con󰈡gured “Monitoring lockable” to
“Yes” are locked.
4.4
Con󰆟gure Application
4.4.1
Application Mode
General notes
These parameters determine in which breaker mode the LS-5 operates the breaker. The
device can be con󰈡gured to a 1- or 2-breaker control by these parameters. These
parameters have to be adjusted as early as possible, because they pre-con󰈡gure other
parameters.
This manual describes only the LS-5
con󰈡gured as 2-breaker control (parameter 9018).
The LS-5 con󰈡gured as 2-breaker control can be con󰈡gured to three di󰈠erent application
modes:
Application mode Symbol
Single LS5
A01
LS5
A02
L-GGBMCB
A05
For additional information refer to ╚═▷ “6 Application”.
151LS-5 v2 Series37650
4 Con󰈡guration
4.4 Con󰈡gure Application
Released
