Fixed parameters
In the application mode
A05
some parameters are precon󰈡gured to 󰈡xed values. In this
mode these parameters cannot be accessed via front panel or ToolKit.
Check the following parameters if you change the application mode from
A05
to
A02
or
A01
.
Device number (parameter 1702) Variable system (parameter 8816)
Node-ID CAN bus 1 (parameter 8950) Synchronization mode (parameter 5728)
Startup in mode (parameter 8827) Mains power measurement (parameter 8813)
Segment number System A (parameter 8810) Dead bus closure (parameter 3432)
Segment number System B (parameter 8811) Connect A dead to B dead (parameter 8802)
Mains connection (parameter 8814) Connect A dead to B alive (parameter 8803)
Max. phase angle (parameter 8821) Connect A alive to B dead (parameter 8804)
'Connect open load to A dead' (parameter 9013) Connect synchronous mains (parameter 8820)
'Connect open load to A alive' (parameter 9014) Delay time phi max. (parameter 8822)
'Connect open load to B dead' (parameter 9015) Transfer time CBA <-> CBB (parameter 3400)
'Connect open load to B alive' (parameter 9016) Open CBA in manual (parameter 8828)
ID Parameter CL Setting range
[Default]
Description
9018 Breaker mode LS5 1 CBA The device supports one circuit
breaker, signed as CBA and one
isolation switch. (Also named as
LS-5x1 mode).
Notes
If the LS-5 is con󰈡gured to this mode
(one breaker) please refer to the
according manual.
[CBA / CBB] The device supports two circuit
breakers signed as CBA and CBB with
a load path in-between. (Also named
as LS-5x2 mode)
8992 Application mode CBA/CBB 1 Single LS5
Application mode
A01
In this application mode there is only
one single LS-5 unit installed.
L-GGBMCB
Application mode
A05
In this application mode the easYgen
controls the GGB and the MCB via the
LS-5. The operation mode is 󰈡xed to
automatic.
[LS5]
Application mode
A02
152 LS-5 v2 Series 37650
4 Con󰈡guration
4.4 Con󰈡gure Application
