USER GUIDE (COPIER)
1–7
U
SER
G
UIDE
(C
OPIER
)
Touch Screen
The Touch Screen is used to select features on the User Interface.
Press the buttons and tabs displayed in the Touch Screen to set
features or to instruct operations on screens. The selected buttons
are highlighted to indicate activation. Buttons that do not have
three-dimensional shadows are not active, and cannot be
selected.
Message Area Messages such as machine status and operation instructions are
displayed here
Unused Memory The amount of memory remaining to store a scanned original is
displayed prior to output.
Quantity The copy quantity is entered using the keypad, and appears in the
upper right corner of the message area. Select between 1 - 999.
Tab Feature Tabs displayed on the Touch Screen contain the
programmable selections available for each feature.
Selection Buttons Allow for the selection of feature / functions required for the
desired output. Buttons identified, as More… have additional
features, which will be displayed when this button is selected.
Power Switch
The power switch is located on the right top corner of the machine.
Press the switch to the ( | ) position to turn the power on. The
machine is ready to make copies in approximately 45 seconds.
Ground Fault Protector Located at the rear of the machine where the power cord attaches.
The Ground Fault Protector removes all power from the machine if
a fault is detected in the power to the copier/printer. To reset the
GFI, press the switch in.
Message
Area
Unused
Memory
Quantit
Tab
Selection
Buttons
