2–88
U
SER
G
UIDE
(P
RINT
)
Adjusting Color Balance
You can adjust the toner density of Cyan, Magenta, Yellow, Black
(CMYK) for printing. Each color can be adjusted to low/medium/
high density and in seven levels each within the range of -3 to 3.
Display the Color Balance tab to adjust these settings.
NOTE: When Output Color of the Graphics tab has been
selected as Black/White, only black can be adjusted here.
1
Select Print from the File menu.
2
Check Printer, and then click Properties.
3
Click the Graphics tab and then the Color Balance button.
• The Graphics dialog box will be opened with the Color
Balance tab displayed.
4
Check the Adjust Color Balance check box.
5
Select the color to be adjusted from the list box below.
6
Adjust the density.
• Use the up and down arrow buttons located below the
graphs of low/medium/high density to adjust the settings.
7
Click OK.
To Next Page
