1–76
U
SER
G
UIDE
(C
OPIER
)
Duplex Automatic Document Feeder (DADF)
This section describes the Duplex Automatic Document Feeder
(DADF) for the DocuColor Series copier/printer.
The DADF automatically feeds up to 50 sheets of the same size
documents or mixed size documents, one at a time, onto the
Document Glass, feeding the top sheet first. Documents are
delivered to the Original Catch Tray after they have been copied.
NOTE: If the DADF belt is dirty and the original is a thin or
transparent document, background may appear on the output.
This may also occur when copies are made using the Document
Glass. Place a white sheet of paper of the same size on top of the
document being copied to eliminate background until the belt is
cleaned.
Component Names and Functions
The following items are the principal components of the Duplex
Automatic Document Feeder.
Document Feed Lamp This lamp displays a green arrow when a document is inserted
correctly into the feeder. This light can also indicate a document
jam.
Original Catch Tray Documents are delivered to this tray.
Original Input Area Place documents here to start copying.
