USER GUIDE (MACHINE
ADMINISTRATOR)
4–51
U
SER
G
UIDE
(M
ACHINE
A
DMINISTRATOR
)
Setting Reduce/Enlarge Presets
Set the ratios displayed in Reduce/Enlarge on the Scan Options
screen in Scan mode.
Any ratio can be assigned to R/E Preset 1 ~ 7, except for 100%.
Setting frequently used magnification rate saves you from having
to change the setting each time.
R/E Preset 1 ~ 7 Enter the setting using the number buttons listed in the following
table. The defaults are as follows, starting from R/E Preset 1: 3,
50.0%, 7, 70.7%, 8, 81.6%, 9, 86.6%, 10, 115.4%, 11, 122.4%,
and 13, 141.4%.
Setting Description Setting Description
1 25.0% 10 115.4%
2 35.3% 11 122.5%
3 50.0% 12 129.4%
4 57.7% 13 141.4%
5 61.2% 14 163.2%
6 64.7% 15 173.2%
7 70.7% 16 200.0%
8 81.6% 17 282.8%
9 86.6% 18 400.0%
