1–78
U
SER
G
UIDE
(C
OPIER
)
Loading the Documents
Placing Documents on the Document Glass
1
Open the DADF.
2
Place the document face down, and align it against the inside left
cover of the Document Glass.
3
Close the DADF.
Loading Documents in the DADF
You can load up to 50 documents from 16 lb. to 32 lb. (64 to 128
gsm) into the DADF.
1
Remove any paper clips or staples from the documents. Align the
documents.
2
Place the documents face up in the Original Input Area of the
DADF. Slide the documents to the left until the green Document
Feed Lamp lights.
If the lamp does not light, readjust the alignment and or the
placement of the documents until the lamp lights.
3
Slide the document guide toward the stack of documents until the
guide lightly touches the side edges of the documents. If the
document guide is set too tight, the documents may not feed or
may become damaged. If the guide is set too loose, the
documents may skew as they feed, which could cause a
document jam.
4
Extend the DADF Original Catch Tray to accommodate the size of
the documents.
5
Press the Start button.
The documents automatically feed one by one, onto the
Document Glass. The feeding begins from the top of the stack of
documents.
To Next Page
