WorkCentre 3210/3220 Multifunction Printer Service Manual 3-11
Error Messages and Codes
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Main Controller Board, PL1.0.2
■ Power Supply, PL1.0.4
■ Feed Actuator, PL4.0.72
■ Fuser, PL8.0.0
■ Exit Sensor, PL8.0.37
■ Map 5 - Main Controller Board
■ Map 7 - Power Supply
■ Power and Fuser
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the Feed Actuator installation.
Reseat the Feed Actuator.
Does the error still occur?
Replace the
Feed Actuator
(page 8-82).
Go to step 2.
Complete.
2 Does the error still occur? Go to step 3. Complete.
3 Check the Exit Sensor for damage.
Is the Exit Sensor damaged?
Replace the Exit
Sensor
(page 8-93).
Go to step 4.
4 Check the Power Supply installation.
Reseat Power Supply connections.
Does the error still occur?
Replace the
Power Supply
(page 8-104).
Go to step 5.
Complete.
5 Check the Main Controller Board for
correct installation. Reseat the Main
Controller Board.
Does the error still occur?
Replace the
Main Controller
Board
(page 8-100).
Complete.

Xerox WorkCentre 3220 Specifications

General

Print Technology	Laser
Print Resolution	Up to 600 x 600 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 4800 x 4800 dpi (enhanced)
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
ADF Capacity	50 sheets
Monthly Duty Cycle	Up to 30, 000 pages
Functions	Print, Copy, Scan, Fax
Memory	64 MB
Duplex Printing	Manual
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Maximum Paper Size	8.5 x 14 in (Legal)
