Xerox WorkCentre 3220 Service Manual

10-20 WorkCentre 3210/3220 Multifunction Printer Service Manual
Wiring
ADF and Scanner
Main Controller
Board
CN16
+3.3VDC
s3210mfp-110
CON3
Scanner Control
Scanner
Motor
AFE_SIG
SCAN_CONTROL_1
GND
GND
CIS_3.3V
CIS_12V
CIS_BLED
CIS_GLED
CIS_RLED
CIS_OFFSET
CIS_SP
CIS_CLK
1
2
3
4
5
6
7
8
9
10
11
12
1
2
3
4
5
6
7
8
9
10
11
12
CN8
CN??
Control Panel
PANEL_RXD
GND
nSCANNER_HOME
1
2
3
4
5
6
7
8
13
14
15
16
13
14
15
16
8
7
6
5
4
3
2
1
nRST_PANEL
PANEL_TXD
MOD_BUZZER
KEYCLICK
+5VDC
+24VDC
+5VDC
+12VDC
CN5 CN??
+3.3VDC
ADF Control
Board
GND
GND
GND
nADF_P_DET
nADF_P_REGI
nADF_P_POS
ADF_MOT_NB
ADF_MOT_PHB
ADF_MOT_PHA
ADF_MOT_B
ADF_MOT_A
ADF_MOT_NA
1
2
3
4
5
6
7
8
9
10
11
12
1
2
3
4
5
6
7
8
9
10
11
12
GND
GND
+12VDC
+24VDC
CN3
1
2
3
OUT1A
OUT1B
OUT2A
OUT2B
4
M
Paper
Empty
Sensor
Registration
Sensor
Paper
Exit
Sensor
CN??
CN??
ADF Motor
ADF_MOTOR_READY
M
nADF_MOTOR_EN
GND
ADF_MOTOR_BREAK
GND
GND
10
9
8
7
6
5
4
3
2
1
nADF_MOTOR_DIR
ADF_CLK
+24VDC
+24VDC
1
2
3
4
5
6
7
8
9
10
