Xerox WorkCentre 3220 Service Manual

1-18 WorkCentre 3210/3220 Multifunction Printer Service Manual
General Information
Warm-Up Time
Warm-up Time is defined as the time when the printer changes from Power-
On to Standby mode.
■ From Power On (UI Ready): Less than 54 seconds
■ From Power On (First Page Print): Less than 17 seconds
Image Specifications
Note
The printer produces a 4 mm margin on all sides. Edge-to-edge printing is
not available.
Print Margins
Print Area Margin
Guaranteed Print
Quality Area
Paper Width (A+B) A = Left Margin 4.23 mm
B = Right Margin 4.23 mm
Paper Length
(C+D)
C = Top Margin 4.23 mm
D = Bottom Margin 4.23 mm
Maximum 3 mm from edge of paper
Characteristic Specifications
Skew
Vertical
■ ±2.0 mm (Tray 1) / 241.3 mm
(Based on 0.0082 mm/mm)
■ ±2.5 mm (Duplex, SCF) / 241.3 mm
(Based on 0.0103 mm/mm)
■ ±3.5 mm (ADF) / 241.3 mm
(Based on 0.0103 mm/mm)
Horizontal
■ ±1.5 mm (Tray 1: ± 2.0 mm) / 177.8 mm
(Based on 0.0084mm/mm)
■ ±2.0 mm (Duplex, SCF) / 177.8 mm
(Based on 0.0112mm/mm)
■ ±2.5 mm (ADF) / 177.8 mm
(Based on 0.0112mm/mm)
Registration
Left Print Position
(scanning direction)
± 2.5 mm (±3.0 mm, Duplex)
Top Print Position
(feeding direction)
± 3.0 mm (±3.0 mm, Duplex)

Xerox WorkCentre 3220 Specifications

General

Print Technology	Laser
Print Resolution	Up to 600 x 600 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 4800 x 4800 dpi (enhanced)
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
ADF Capacity	50 sheets
Monthly Duty Cycle	Up to 30, 000 pages
Functions	Print, Copy, Scan, Fax
Memory	64 MB
Duplex Printing	Manual
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Maximum Paper Size	8.5 x 14 in (Legal)
