Xerox WorkCentre 3220 Service Manual

5-36 WorkCentre 3210/3220 Multifunction Printer Service Manual
Print-Quality Troubleshooting
TP 5 Ghosting
TP 5 is used to check ghosting effects in the grey portion of the print. Refer to
“Repeating Defects” on page 5-10 to determine the component.
TP 6 Black Solid Fill
TP 6 is used to check for dropout (white spot) performance, banding, and
image fixing (fusing).
s3210mfp-201
GHOSTING
s3210mfp-202

Xerox WorkCentre 3220 Specifications

General

Print Technology	Laser
Print Resolution	Up to 600 x 600 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 4800 x 4800 dpi (enhanced)
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
ADF Capacity	50 sheets
Monthly Duty Cycle	Up to 30, 000 pages
Functions	Print, Copy, Scan, Fax
Memory	64 MB
Duplex Printing	Manual
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Maximum Paper Size	8.5 x 14 in (Legal)
