Xerox WorkCentre 3220 Service Manual

WorkCentre 3210/3220 Multifunction Printer Service Manual 3-23
Error Messages and Codes
Fuser Errors
Warning
Hazardous voltage is connected to the Fuser. Remove the Power Cord from
the printer before starting the procedure.
Fuser Heat Errors
There is a Fuser thermal error.
Warning
Allow the Fuser to cool before starting the procedure.
Applicable Error Messages
■ Open Heat Error
■ Low Heat Error
■ Over Heat Error
Initial Actions
■ Check the Fuser for damage or debris.
■ Cycle printer power.
■ If the problem persists, refer to the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map Reference
■ Fuser, PL8.0.0
■ Thermistor, PL8.0.5
■ Thermostat, PL8.0.7
■ Halogen Lamp, PL8.0.30
■ Map 5 - Main Controller Board
■ Map 7 - Power Supply
■ Map 8 - Left Side Harness
■ Power and Fuser
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Reseat the Fuser connections.
Does the error still occur?
Go to step 2. Complete.
2 Run the Fuser Temp test from EDC.
Does the Thermostat operate
correctly?
Go to step 3. Replace the
Thermostat
(
page 8-16).

Xerox WorkCentre 3220 Specifications

General

Print Technology	Laser
Print Resolution	Up to 600 x 600 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 4800 x 4800 dpi (enhanced)
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
ADF Capacity	50 sheets
Monthly Duty Cycle	Up to 30, 000 pages
Functions	Print, Copy, Scan, Fax
Memory	64 MB
Duplex Printing	Manual
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Maximum Paper Size	8.5 x 14 in (Legal)
