Xerox WorkCentre 3220 Service Manual

WorkCentre 3210/3220 Multifunction Printer Service Manual 3-31
Error Messages and Codes
System Errors
Main Motor Locked
The Drive Unit Assembly has stopped rotating.
Applicable Error Message
■ Main Motor Locked
Initial Actions
■ Cycle printer power.
■ If the problem persists, refer to the following procedure.
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the USB memory device,
Press the Direct USB button.
Does the printer detect the device?
Go to step 2. Go to step 3.
2 Check the USB memory device in a
different machine.
Is the device readable?
Go to step 3. The device is
damaged or
formatted
incorrectly
3 Check for +5V at the USB Host Board
connection to the Main Controller
Board CN15-1.
Is +5V present at CN15-1?
Go to step 4. Replace the
Main Controller
Board
(
page 8-100).
4 Check the wiring harness between the
USB Host Board and the Main
Controller Board.
Is the harness damaged or
disconnected?
Repair or
connect the USB
host harness.
Replace the
USB Host PBA
(
page 8-56).
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Main Controller Board, PL1.0.2
■ Drive Unit Assy, PL5.0.0
■ Map 2 - Drive Locator
■ Map 5 - Main Controller Board
■ Main Controller Board

Xerox WorkCentre 3220 Specifications

General

Print Technology	Laser
Print Resolution	Up to 600 x 600 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 4800 x 4800 dpi (enhanced)
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
ADF Capacity	50 sheets
Monthly Duty Cycle	Up to 30, 000 pages
Functions	Print, Copy, Scan, Fax
Memory	64 MB
Duplex Printing	Manual
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB 2.0, Ethernet
Maximum Paper Size	8.5 x 14 in (Legal)
